- Displacement : 290 cc/rev.
- Pressure : Max. 30 Bar
- Viscosity : Max. 1,000,000 cp
- Temperature : Max. 200 ℃
Dimensions
A: 110 mm, B : 140mm, C: 211mm, D: 35mm, E: 35mm, F: 40mm, G: 58mm, H: 130mm, I-1: 24.5mm, I-2: 161mm, J: 40mm, K: 32mm, L-1: 295mm, L-2: 355mm, M: 240mm, N: 10x8, O: 172mm, Diameter for 4 Holes of Base: 13mm
Applications : Beverage, Dairy, Pharmaceutical, Paste, etc.
