Displacement : 370 cc/rev.

Pressure : Max. 30 Bar

Viscosity : Max. 1,000,000 cp

Temperature : Max. 200 ℃

Dimensions

A: 110 mm, B : 140mm, C: 211mm, D: 35mm, E: 35mm, F: 44mm, G: 73mm, H: 130mm, I-1: 24.5mm, I-2: 161mm, J: 40mm, K: 32mm, L-1: 295mm, L-2: 428mm, M: 240mm, N: 10x8, O: 172mm, Diameter for 4 Holes of Base: 13mm

Applications : Beverage, Dairy, Pharmaceutical, Paste, etc.
