Displacement : 50 cc/rev.
Pressure : Max. 1 Bar
Viscosity : Max. 10,000 cp
Temperature : Max. 100 ℃
Dimensions
MODEL | Type |
A | B | C | D | E | F | G | H |
I |
J | K | L | M | N | 4-Φ |
DS-L1SM09 | A | 60 | 120 | 150 | - | 108.5 | 27 | 30.5 | 84.5 | 65.5 | 40 | 14 | 223 | 149.5 | 5×5 | 9 |
DS-L1SM18 | I | 60 | 150 | 171.5 | - | 69 | 27 | 30.5 | - | 65.5 | 40 | 14 | 223 | 144.5 | 5×5 | 9 |
L | 60 | 150 | 171.5 | 40 | 69 | 27 | 30.5 | 33.5 | 65.5 | 40 | 14 | 249 | 144.5 | 5×5 | 9 | |
AL | 60 | 120 | 150 | 40 | 108.5 | 27 | 30.5 | 84.5 | 65.5 | 40 | 14 | 249 | 149.5 | 5×5 | 9 | |
DS-L1.5SM30 | A | 60 | 120 | 150 | - | 108.5 | 33 | 38.5 | 84.5 | 65.5 | 40 | 14 | 237 | 149.5 | 5×5 | 9 |
DS-L1.5SM50 | I | 60 | 150 | 171.5 | - | 69 | 33 | 38.5 | - | 65.5 | 40 | 14 | 237 | 144.5 | 5×5 | 9 |
L | 60 | 150 | 171.5 | 26 | 69 | 33 | 38.5 | 33.5 | 65.5 | 40 | 14 | 263 | 144.5 | 5×5 | 9 | |
AL | 60 | 120 | 150 | 26 | 108.5 | 33 | 38.5 | 84.5 | 65.5 | 40 | 14 | 263 | 149.5 | 5×5 | 9 | |
(units:mm) |
적용분야 : 음료, 유제품, 제약, 장류 등
