Displacement : 85 cc/rev.
Pressure : Max. 10 Bar
Viscosity : Max. 1,000,000 cp
Temperature : Max. 200 ℃
Dimensions
A: 100 mm, B: 100mm, C: 230mm, D: 55mm, E: 55mm, F: 36mm, G: 64mm, H: 100mm, I-1: 29mm, I-2: 127mm, J: 30mm, K: 22mm, L-1: 259mm, L-2: 365mm, M: 180mm, N: 8x7, O: 126.5mm, Diameter for 4 Holes of Base: 9mm
Applications : Chemicals, Oil, Waste Water, Excretions, etc..
