Displacement : 482 cc/rev.
Pressure : Max. 5.5 Bar
Viscosity : Max. 5,000 cp
Temperature : Max. 120 ℃
Dimensions
A: 150mm, B: 55mm, C: 120mm, D: 123mm, E: 39.5mm, F: 38mm, G: 142mm, H: 132mm, I: 12x8, J: 7.5mm, K: 142mm, L: 454mm, M: 74.5mm, N: 162mm, Inlet & Outlet Dia.: 3S, Diameter for 4 Holes of Base: 11mm
Applications : Dairy, Beverages, Jam, Paste, etc..
