Product Name
Function Generator
Model Name
-
Size
-
Weight
-
Product Details
| MODEL | 8210 | 8205 | 8203/8202 | ||||
| Output Characteristics | Waveforms | Sine,Square,Triangle,Ramp,Pulse,Sawtooth,TTL Leveled Squery (CMOS 8203/8202 only) | |||||
| Frequency Range |
0.1 Hz to 10 MHz in 7 Range | 0.05 Hz to 5 MHz in 7 Range |
0.03 Hz to 3 MHz in Range(8203) |
||||
| 0.02 Hz to 2MHz in 7 ranges(8202) |
|||||||
| Frequency Accuracy |
2% of full scale | ||||||
| Output Level | 2% Vp-p in Open circult, 10 Vp-p into 50 Ω Load | ||||||
| Output Impedance |
50Ω ± 5% | ||||||
| Attenuator | 20 dB fixed and continuouly variable | ||||||
| DC Offset Control | More than ±5V (into 50ohm) | ||||||
| Waveform Characerisics |
Sine wave | Flatness: ±3 dB to Maximum Output, Distortion:Less than 1% at 10Hz to 100KHz | |||||
| Square wave | Rise and Fall Time:Less than 120 nS at 1MHz | ||||||
| Triangle wave |
Linearity:More than 99% at0.2 Hz 100kHz | ||||||
| TTL Output |
Rise and Fall time : Less than 25nS at 1MHz | ||||||
| Output Level:TTL Level(H ≥ 2.4 V.Ls 0.4 V) | |||||||
| CMOS Output (8203,8202 only) |
Rise and Fall time : Less than 160 nS | ||||||
| Output Level:4V to 15V ≥ 1V, Variable | |||||||
| Symmery Variation |
1:1 to 10:1 | ||||||
| Sweep Function Characteristics |
Mode | Linear | |||||
| Width | Variable from 1:1 to 100:1 | ||||||
| Rate | 0.5 Hz to 50 Hz(20 mS to 2 S) | ||||||
| Extemal VCF input | Input Voltage:0 to, Input Impedance:Approx 1kohm | ||||||
| Frequency Conuter Characeristics |
Display | 7 digits Green LED | 6 digits Green LED | ||||
| Frequency Range |
0.2 Hz to 100MHz | 0.2 Hz to 50 MHz | |||||
| Acuracy | ± Timebase Error ± 1 count | ||||||
| Low pass Filter |
Approx, -3 dB, 100kHz | ||||||
| Timebase | 10 MHZ x-TAL, ± 20PPM | ||||||
| Input Sensitivity | 100mVrms | ||||||
| Max, Input Voltage |
48 Vp-p | ||||||
| General | Power Requirement | 115 or 230 VAC ± 10%, 48 to 66Hz | |||||
| Operationg Temperature |
0 to 50º C ( Acuracy spcified at 23 ± 5ºC ) | ||||||
| Dimension | 240(W) x 270 (D) x 90(H) mm | ||||||
| Weight | Approx, 3kg | Approx, 2kg | |||||
| Standard Accessories |
Power Cord, BNC Cable, Fuse, Instruction Manual | ||||||
