Features
- High precision hydraulic oil flow controlled
- High cutting efficiency by hinge type
- Precise control of chuck revolution by cycloid gear box
- Capable of cutting wide rage of rings
- Cast iron band wheels(FCD-45) with heat treatment
- High precision reducer and robust body structure
- Hydraulic controled blade tension device
- Safety upgrade by cutting depth control devise
- Longer blade life by minimum twisting of blade
- Easy blade replacement by one touch blade clamping unit
- Work light
Specifications
MODEL | SFA-1540R | |
Control | PLC CONTROL | |
Cutting Capacity | Ø360~Ø1350 | |
Cutting Capacity |
Size | 5300×41×1.3 (mm) |
Speed | 24,27,42,54,67 m/min | |
Tension | Hydraulic | |
Chuck | Revolution | 0.1~1rpm |
Storke | 280mm | |
Motor | Chuck | 2HP |
Drive | 5HP | |
Hydraulic | 2HP | |
Coolant | 1/4HP | |
Tank Capacity | Hydraulic | 60ι |
Cutting Fluid | 80ι | |
Weight | 3,500kg | |
Measurement(W×L×H) | 2600×1900×2500 (mm) |
