Inverted Angle

Model Name

Series

Angle

View AllView All Series

Data

Manufacturer information

FINE BESTEEL

Inverted angle steel, unequal angle steel, angle channel and i-beam

Inquiry

How to order

Problem with product info?

Update request

Manufacturer

FINE BESTEEL

Brand

SKU

141056

Product Name

Inverted Angle

Model Name

Size

Weight

Product Details

Descriptions

Also called an angle, it is a rolled section steel with two sides at right angles. There are equal ㄱ-section steel, unequal ㄱ-section steel, and inverted ㄱ-section steel, which are mainly used for truss members, shipbuilding and steel towers.

Dimensions and Sectional Properties

Nominal Size	Standard Sectional Dimension (mm)					Sectional Area (cm²)	Unit Weight (kg/m)	Center of Gravity (cm)		Moment of Inertia (cm²)				Radius of Gyration (cm)				tan α	Modulus of Section (cm²)
Nominal Size	A x B	t₁	t₂	r₁	r₂	A	W	Cx	Cy	lx	max ly	min lu	lv	ix	max ly	min iu	iv	tan α	Sx	Sy
200x90	200x90	10	14	14	7	31.52	24.7	6.61	2.08	1,297	202	1,290	125	6.41	2.53	6.41	2.53	0.263	96.9	29.2
250x90	250x90	10	15	17	8.5	37.47	29.4	8.61	1.92	2,440	223	2,520	147	8.08	2.44	8.20	1.98	0.182	149	31.5
250x90	250x90	12	16	17	8.5	42.95	33.7	8.99	1.89	2,790	238	2,870	160	8.07	2.35	8.18	1.93	0.173	174	33.5
300x90	300x90	11	16	19	9.5	46.22	36.3	11.0	1.76	4,370	245	4,440	168	9.72	2.30	9.80	1.90	0.136	229	33.8
300x90	300x90	13	17	19	9.5	52.67	41.3	11.3	1.75	4,940	259	5,020	181	9.68	2.22	9.76	1.85	0.128	264	35.8
350x100	350x100	12	17	22	11	57.74	45.3	13.0	1.87	7,440	362	7,550	251	11.3	2.50	11.4	2.08	0.124	338	44.5
400x100	400x100	11.5	16	24	12	61.08	48.0	15.28	1.71	10,284	349	11,600	277	13	2.39	13	2.39	0.0996	416	42.1
400x100	400x100	13	18	24	12	68.59	53.8	15.4	1.77	11,500	388	11,600	277	12.8	2.38	13	2.01	0.0996	467	47.1
450x125	450x125	11.5	18	24	12	73.11	57.4	16.2	2.29	15,700	768	16,000	525	14.7	3.24	14.8	2.68	0.126	547	75.2
