Rtorvator Manufacturer, Suppressor, Weeding Machine, Compost Sprayer and more
• The powerful large sized side gear is used
• The new conceptual hightech steel materials are used
• The heatsink wings for the gear box and the window
for an oil lactoscope is attached
• Possible to install various blades fit into the soils and working environments
• A driving axle of harrow breaking used a special group sealing for a completely wareproof
Model | Drive | Working Width | HP | Weight | N.Blade | N.Flange | Total Length | Width | Height | ||||||
cm | inc | min | max | Kg | Lbs | cm | inc | cm | inc | cm | inc | ||||
GMR205HL | SIDE GEAR |
205 | 80 | 65 | 80 | 530 | 1175 | 48 | 8 | 99 | 40 | 222 | 87 | 141 | 56 |
GMR215HL | 215 | 85 | 75 | 85 | 535 | 1185 | 48 | 8 | 99 | 40 | 230 | 90 | 141 | 56 | |
GMR220HL | 220 | 87 | 80 | 105 | 545 | 1205 | 54 | 9 | 99 | 40 | 240 | 95 | 141 | 56 | |
GMR230HL | 280 | 90 | 85 | 110 | 560 | 1240 | 54 | 9 | 99 | 40 | 250 | 100 | 141 | 56 | |
GMR240HL | 300 | 95 | 90 | 110 | 570 | 1260 | 60 | 10 | 99 | 40 | 260 | 105 | 141 | 56 |
