Manufacturer of Smart seeding system, Seeder, Power planter, Forest cultivating system and more
Convenient Seeder (SD-1800W)
|
Dimension(mm) |
L |
1,800 |
|
W |
790 |
|
|
H |
1,300 |
|
|
Weight(kg) |
200kg |
|
|
Power(W) |
1P 80 |
|
|
Compressed air |
6kg/㎠ |
|
•Dibbling + Seeding + Covering soil function
•Possible to connect & install water irrigator on the front side, on the rear side of medium filler in future.
•Manifold: Supply customer specified 1 piece set
Private Seeder(SD-600)
|
Dimension(mm) |
L |
920 |
|
W |
470 |
|
|
H |
380 |
|
|
Weight(kg) |
30kg |
|
|
Power(W) |
1P 15 |
|
|
Compressed air |
5kg/㎠ |
|
•Private seeding by cooperative unit or farmhouse unit (lettuce, onion, flower etc)
•Easy to carry out moving tour work due to an ultra-light weight(30kg)
•Manifold: Supply customer-specified 1 piece set
Stepping Seeder (SD-1200S)
|
Dimension(mm) |
L |
1,400 |
|
W |
790 |
|
|
H |
920 |
|
|
Weight(kg) |
150kg |
|
|
Power(W) |
1P 40 |
|
|
Compressed air |
6kg/㎠ |
|
•Secure private seeding by standstill seeding
•Function of seeding of multiple seeds in a cell
•Able to seed uniformly even on any kind of seeding plate
•Work by setting the distance between cells, not by optical sensor
•Stepping dibbler is separately made as a sister product.
Large Seed Seeder (SD-1212)
|
Dimension(mm) |
L |
1,400 |
|
W |
790 |
|
|
H |
920 |
|
|
Weight(kg) |
150kg |
|
|
Power(W) |
1P 40 |
|
|
Compressed air |
6kg/㎠ |
|
•Stock seeding for grafting preparation like pumpkin, gourd.
•Possible to installin the middle of the existing seeding system line
•Seeding of seed soaked is recommended after removing water.
•Seeding forest trees seed such as landscape plants, economic trees etc.
