Hardmetal tool, Drill, End mill. Reamer, Cutter blade
WB3○○ series(Type 1)
(Unit:mm)
CODE |
FLUTE |
DIMENSIONS(mm) |
|||
H |
L |
A |
B |
||
WB 301 |
1 |
89 |
350 |
2 |
3 |
WB 302 |
1 |
89 |
440 |
2 |
3 |
WB 303 |
1 |
89 |
610 |
2 |
3 |
WB 304 |
1 |
89 |
350 |
3 |
3 |
WB 305 |
1 |
89 |
440 |
3 |
3 |
WB 306 |
1 |
89 |
610 |
3 |
3 |
WB 307 |
1 |
89 |
350 |
4 |
4 |
WB 308 |
1 |
89 |
440 |
4 |
4 |
WB 309 |
1 |
89 |
610 |
4 |
4 |
WB 310 |
1 |
89 |
350 |
5 |
5 |
WB 311 |
1 |
89 |
440 |
5 |
5 |
WB 312 |
1 |
89 |
610 |
5 |
5 |
WB 313 |
1 |
89 |
350 |
6 |
6 |
WB 314 |
2 |
89 |
440 |
6 |
6 |
WB 315 |
2 |
89 |
610 |
6 |
6 |
WB 316 |
2 |
89 |
350 |
7 |
6 |
WB 317 |
2 |
89 |
440 |
7 |
6 |
WB 318 |
2 |
89 |
610 |
7 |
6 |
WB 319 |
2 |
89 |
350 |
8 |
8 |
WB 320 |
2 |
89 |
440 |
8 |
8 |
WB 321 |
2 |
89 |
610 |
8 |
8 |
WB 322 |
2 |
89 |
350 |
9 |
8 |
WB 323 |
2 |
89 |
440 |
9 |
8 |
WB 324 |
2 |
89 |
610 |
9 |
8 |
WB 325 |
2 |
89 |
350 |
10 |
10 |
WB 326 |
2 |
89 |
440 |
10 |
10 |
WB 327 |
2 |
89 |
610 |
10 |
10 |
WB 328 |
2 |
89 |
800 |
10 |
10 |
