Model Name
Mesh Belt Oven
Series
-
Data
-
Manufacturer information
JTEKT KOREADeep Groove Ball Bearings, Angular Contact Ball Bearings, Spherical Roller Bearings, Tapered Roller Bearings, Oil Seals and more
Problem with product info?
Update request
Manufacturer
JTEKT KOREA
Brand
-
SKU
122095
Product Name
전자부품 연속 열처리 장비
Model Name
Mesh Belt Oven
Size
-
Weight
-
Product Details
Mesh Belt Standard Muffle Type
| Maximum Temperature | 1150℃ |
| Heating Zone | Heat resisting Muffle |
| Belt Width(mm) | 150~800 |
| Atmosphere | N2, N2(Wet), N2+Air, Air |
| Applications | Brazing, Soldering, Reflow, Firing( mataliic condutor・resistant・derivative), Electrode drying, Debinding, Encapsulation, Matal Anneal |
Mesh Belt Hydrogen Atmosphere Type
| Maximum Temperature | 1150℃ |
| Heating Zone | Heat resisting Muffle |
| Belt Width(mm) | 150~800 |
| Atmosphere | N2 + H2 (WET/DRY) |
| Applications | Brazing, Soldering, Reflow, Firing( mataliic condutor・resistant・derivative), Electrode drying, Debinding, Encapsulation, Matal Anneal |
Ceramic Conveyor Type Continuous Furnace
| Maximum Temperature | 1400℃( Ceramic Muffle) ~ 600℃(Heat resisting Muffle) |
| Transport Method | Ceramic Belt Transport |
| Heating Zone | Heat resisting Muffle or Ceramic Muffle |
| Belt Width(mm) | 200mm ~ |
| Atmosphere | Air, N2(WET/DRY) |
| Applications | Ferrite sintering, MLCC Firing, Glass Brazing, Themistor Firing, Ceramic Sensor Firing |
Small Type Conveyor Furnace
| Type | 801A / 810A-II |
| Maximum Temperature | 1000℃ |
| Normal temperature range | 250℃ ~ 900℃ |
| Temperature Control | Temperature control(PID control) |
| Number of Heating Zone | 4, 5, 7 ( To be discussed for number of heating zone) |
| Heating Zone Length | 969mm(4 ZONE), 1216mm(5 ZONE), 1704mm(7 ZONE) |
| Heater | Moldatherm |
| Belt Width(mm) | 100, 120 / 150, 200 |
| Loading Weight | 1kg/m ~ 2kg/m |
| Conveyor Speed | Standard 15~150mm( Non-standard is Possible ) |
| Outside Demension | [4 ZONE]3000(L)×530(W)×1360(H) / [4 ZONE]3000(L)×610(W)×1360(H) [5, 7 ZONE]3700(L)×530(W)×1360(H) / [5, 7 ZONE]3700(L)×610(W)×1360(H) |
| Applications | Brazing, Soldering, Reflow, Firing( mataliic condutor・resistant・derivative), Electrode drying, Debinding, Encapsulation, Matal Anneal |
