Cooling Fan Controller of Armored Vehicle Engine
Model Name
-
Series
Electronic Equipment Component
Data
-
Manufacturer information
provider logo
KUKDONG ELECTRONIC PRECISION

Connector and Cable manufacturer, Electric / Electronic parts, Defense industry equipment and more

Problem with product info?
Update request
Manufacturer
KUKDONG ELECTRONIC PRECISION
Brand
-
SKU
50080
Product Name
Cooling Fan Controller of Armored Vehicle Engine
Model Name
-
Size
-
Weight
-
Product Details
Application

Feature

Armored Vehicle Engine of Next Generation  1) Fan(Digital) Controller
    Size : 125(W)×80(D)×58(H)mm
    Weight : 0.545Kgf
    Power : DC24V ~ 28V
    Controlling Method : the Position of Linear Solenoid Spool is controlled by PWM (Pulse Width Modulation) output Signal according to the temperature values of air and cooling water in engine.
 2) Fan(Digital) Controller
    Size : 85(W)×28(D)×28(H)mm
    Weight : 0.130Kgf
    Controlling Method : Sensor embedded with Negative Differential Resistance Thermistor whose voltage value varies according to the temperature transmitted to the sensor body.
 3) Temperature Sensor(for cooling water)
    Size : 60(W)×28(D)×28(H)mm
    Weight : 0.100Kgf
    Controlling Method : Sensor embedded with Thermistor whose voltage value varies according to the temperature transmitted to the sensor body.
KUKDONG ELECTRONIC PRECISION
Connector and Cable manufacturer, Electric / Electronic parts, Defense industry equipment and more
Kukdong Electronic Precision Co., Ltd. was established in 1998. Though young, we have been very aggressively involved in our national Economic Development. In National defense we localized raw material for the manufacture of parts used in our National Defense equipment. We also are moving forward step by step with a powerful force that will lead us into the new era of 21st century. We specialize in the manufacturing of connectors, cable harness and electronic equipment components. Our products are not solely used by the Korean Army. It is also widely used by local defense equipment manufacturers. We deliver MS/VG style connectors to U.S.A, Australia, U.K., China, Taiwan, Japan and Thailand. We are one of the leader in the use of localization of parts from development stage to final. We work closely to establish the final product with the defense equipment manufacturers.
