DECODING CAPABILITY

 1D / Linear Codes

 Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes.

 2D Codes

 Aztec Code; China Han Xin Code; Data Matrix; MaxiCode;

 Micro QR Code; QR Code

 Postal Codes

 Australian Post; China Post; IMB; Japanese Post; KIX
 Post; Planet Code; Portuguese Post; Postnet; Royal Mail
 Code (RM4SCC); Swedish Post

 Stacked Codes

 EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacke d; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF;
MicroPDF417; PDF417; UPC A/E Composites

ELECTRICAL

 Battery

 Li-Ion 3350 mAh; Charge Time: External Power: 4.5 Hours; Host Power: 10 Hours

 Reads Per Charge

 40,000+ (continuous reading)

 Cradle Indicator LEDs

 Battery Charging (Red); Charge Completed (Green); Power/Data (Yellow)

 Cradle Consumption

 External Power < 8W; POT: Max 500 mA when in host/bus powered mode.

 Input Voltage

 External: 10 - 30 VDC; POT: 5 VDC +/- 10%

ENVIRONMENTAL

Ambient Light

Immune to light exposure in offices/facilities and direct exposure to sunlight.

Drop Resistance

Withstands 50 drops from 2.0 m / 6.5 ft to a concrete.

ESD Protection (Air Discharge)

20 kV

Humidity (Non-Condensing)

0 - 95%

Particulate and Water Sealing

IP65

Temperature

Operating: -20 to 50 °C / -4 to 122 °F
Storage/Transport: -40 to 70 °C / -40 to 158 °F

INTERFACES

Interfaces

Keyboard Wedge RS-232
USB: OEM USB; USB COM; USB HID Keyboard;

Optional Ethernet (Standard, Industrial)

PHYSICAL CHARACTERISTICS

Colors Available

Yellow/Black

Dimensions

Cradle: 24.0 x 10.8 x 9.5 cm / 9.4 x 4.3 x 3.8 in
PBT9501-AR: 21.2 x 11.0 x 7.4 cm / 8.3 x 4.3 x 2.9 in

Weight

 460.0 g / 16.2 oz

READING PERFORMANCE

Light Source

LED

인쇄선명도 (최소)

15%

Reading Angle

Pitch: +/- 80; Roll (Tilt): +/- 180°; Skew (Yaw): +/- 60°

Field of View

Near Field: 14°(H) x 10.5°(V);Over 3 m / 10 ft: 14.4°(H) x 10.8°(V)

Reading Indicators

Beeper; Datalogic Three Green Lights (3GL™) Good Read Feedback; Datalogic ‘Green Spot’ on the Code; Dual Good Read LEDs; Good Transmission

Resolution (Maximum)

1D Codes: 3 mils; 2D Codes: 4 mils

READING RANGES

Typical Depth of Field

심볼 길이와 각도에 의하여 결정되는 최소 거리;

프린팅 해상도, 대비, 및 내성 조명 의존도.
EAN 13: 20 ~ 290 cm
Code 39: 10 mils: 15 ~ 160 cm
40 mils: 50 ~ 1,100 cm

100 mils: up to 2,300 cm
Code 128: 15 mils: 30 ~ 330 cm
40 mils: 60 ~ 850 cm
100 mils: up to 20 m
DataMatrix: 10 mils: 20 ~ 85 cm

55 mils: 30 ~ 550 cm
100 mils: 30 ~ 880 cm
200 mils: up to 20 m
Note: Reading performances may change with different symbologies; Reading
performances @ 300 lux of ambient light..

SAFETY & REGULATORY

Agency Approvals

The product meets necessary safety and regulatory approvals for

its intended use.See the Regulatory Addendum for details.

Environmental Compliance

Complies to EU RoHS; Complies to China RoHS

Laser Classification

Caution Laser Radiation - Do not stare into beam

CDRH Class II; IEC 60825-1 Class 2

LED Classification

IEC 62471 Exempt Risk Group

UTILITIES

Datalogic Aladdin™

Datalogic Aladdin configuration program is available for download at no charge.

OPOS / JavaPOS

JavaPOS and OPOS Utilities are available for download at no charge.

Remote Host Download

Available on request

WARRANTY

WARRANTY

3-Year Factory Warranty
