Bag Filter

Model Name

Series

Filtration

View AllView All Series

Data

Manufacturer information

Lebe Industrial

Filter housing, Micro filter, Strainer, Industrial filter, Filter device and more

Inquiry

How to order

Problem with product info?

Update request

Manufacturer

Lebe Industrial

Brand

SKU

47178

Product Name

Bag Filter

Model Name

Size

Weight

Product Details

Features

- offers various filter grades and has good tolerance to acid and alkali.

- resistance to high volume of flow and esay relacement of filter

Chemical resistance of bag filter media

- Fibres used as media for bag filters such as polyester, polypropylene, nylon and nomex holds different characteristics depending on its chemical state and temperature.

Polyester

As the most used fibre, it has good economical efficiency, chemical resistance and heat resistance between 150-170℃.

Polypropylene

Widely used in all fields of Chemical Industry due to its good resistance to acidity and basicity. However, it is only applicable within the temperature range of 90-100℃ and it is not suitable for Aromatic Hydrocarbon.

Nylon

Chemical Resistance (except for Acidic Media) and high heat resistance (150-170℃)

A. Excellent B: Normal C: weak

MEDIA	Maximum Operating Temperature (℃)	Base	Acid	Oxidised medium	Alcohol	Ester	alicyclic/aromatic/chloridated			Oil, Fats
MEDIA	Maximum Operating Temperature (℃)	Base	Acid	Oxidised medium	Alcohol	Ester	Aliphatic	Aromatic	Chloride	Oil, Fats
Polyester	150-170	A/B	A/B	B/C	A	A	A	B	A	A
Polypropylene	90-100	A	A	A	A	A	A	C	B	A
Nylon	150-170	A/B	B/C	B	A	A	A	A	A	B/C
Nomex	200-220	A/B	A/B	A	A	A	A	A	A	B
Wool	100-110	C	A/B	C	A	A	A	A	A	A
Fluorpolymer	250-270	A	A	A	A	A	A	A	A	A

Specifications

PE	100	R	4
Filter Media	Micron Rating	Bag Filter	Bag Size
PE = Polyester	1~200㎛	R = Ring type	01 Φ4" x 9"
PP = Polypropylene		P = Plastic Flange	02 Φ4" x 14"
NMO = Nylon		B = Bend type	03 Φ7" x 17"
NMO = Nylon		B = Bend type	04 Φ7" x 32"


MEDIA / MICRON	1	5	10	25	50	100	150	200	400	600	800
PE FELT	●	●	●	●	●	●		●
PP FELT	●	●	●	●	●	●		●
NMO MESH			●	●	●	●	●	●	●	●	●

※ Custom order on request

Lebe Industrial

Filter housing, Micro filter, Strainer, Industrial filter, Filter device and more

Lebe is an industrial corporation specialized in import, manufacture and sales of industrial filter/filtering system established to contribute to a cleaner environment for both living and industrial equipments by the means of filtration of various types of polluted fluids. All our employees work under the vision “Our future lies where there are our clients’ needs are” based on our 20 years of knowledge and experience. We aim to produce and supply the best quality products with pride in craftsmanship.
