No.1 Agricultural machine manufacturer in Korea
Features
Ergonomically designed gear lever Optimized location of levers maximizes space and helps the operator to control the machine easily. | Comfortable seat (slope type) The high-quality ergonomically designed seat enhances comfort to reduce fatigue. | 3-point hitch Category 1 with a hitch lift capacity of 1,320 kgf allows usage of wide variety of implements. |
Your choice of tires Choose ag, industrial or turf tires at no additional cost. | Large fuel tank (52L) The fuel tank provides long operation times between fill-ups. | New LS Tier4 CRDI engine LS Tier4 engine 45/50hp meets EPA’s most stringent emission standards while delivering rated horse power quietly with a low vibration. |
Fender mounted joystick for front ene loader Easily accessible for maximum comfort and convenience. | Independent PTO switch Turn the independent PTO on or off with a simple switch. | Dual pedal, 3range HST (HST model) Easier and more comfortable than rocker pedals. Includes cruise control. |
Specification
| Category | MT3.45E | MT3.50E | |||
| Dimensions& Weight | Overall length, Bumper to link (mm) | 3175 | |||
|---|---|---|---|---|---|
| Overall width with tires (mm) | 1727 | ||||
| Wheelbase (mm) | 1900 | ||||
| Overall height to top ROPS/Cab (mm) | 2540 | ||||
| Total weight without ballast (kg) | 1689 | 1700 | 1689 | 1700 | |
| Tires | Industrial (Front/Rear) | 10.0 - 16.5 / 17.5L - 24 | |||
| Ag (Front/Rear) | 9.5 - 16 / 14.9 - 24 | ||||
| Turf tire (Front/Rear) | 29 x 12.50 - 15 / 44 x 18.00 - 20 | ||||
| PTO | Type | Independent | |||
| Base speed (rpm) | 540 | ||||
| Hydraulic | Control system (options) | Position | |||
| Implement pump (lpm) | 31.2 | ||||
| Category, 3 pt hitch | CAT Ⅰ | ||||
| Hitch lift capacity, Link end (kgf) | 1320 | ||||
| Remote ports *options | 1 or 2 pairs | ||||
| Engine | Type | 3 - CYL. Turbo, CRDI, Water-cooled | |||
| Model | L3C19 - T | ||||
| Emission | EPA & CARB Tier4, EC Stage Ⅲ B | ||||
| Engine Hp (kW) | 45 (33.5) | 50 (37.3) | |||
| PTO Hp | 38.2 | 36.0 | 42.5 | 40.0 | |
| Rated speed (rpm) | 2600 | ||||
| Displacement (cc) | 1879 | ||||
| Fuel Tank Capacity (L) | 52 | ||||
| Traveling system | Transmission Type (options) | Synchro Shuttle Constant mesh | HST | Synchro Shuttle Constant mesh | HST |
| No. of speed | F8 X R8 | 3 Range | F8 X R8 | 3 Range | |
