U50, U60, U6020, U6030, ULTRA65, LS554
New Direct injection Environment friendly Tier III engine is powerful with less fuel consumption and higher durability. * For U6020, U6030 models only. | Large Fuel Tank 80ℓ capacity provides long operation times. | Synchro Shuttle Lever Makes changing direction easier than competitive non-shuttle gear models. |
Electro-hydraulic turn-up/ back-up When tractor turns around or moves reverse, it automatically lifts the implements keeping the operator’s hands free. | Power Shuttle Lever Maximizes ease of use with effortless, clutch-less directional changes. | Large capacity Aircleaner This not only has a higher air purification capacity, it also makes maintenance easier thanks to the longer filter use period. |
Control levers location Control levers are located ergonomically for maximum comfort and convenience. | Loader joystick / Auto Lift When work with Front loader or grader, the loader control lever provides more convenience for its attach/detachment and more productivity for its operation. Auto-lift switch helps the operator easily lift the implements. | Deluxe adjustable seat with retractable seat belt Keeps you safe and comfortable even during long operations. |
Full Flat Deck Full flat deck and rubber mat ensure user-friendly working condition. | Dash Panel All of the important functional data is yours at a glance to keep you in better control of your tractor. | Audio system / Air conditioner Internal speaker and CD/Radio system installed standard and high quality Air-conditioner makes pleasant work time. |
| Category | U50 ROPS | U50 CABIN | U60 ROPS | U60 CABIN | |
| Dimensions & Weight | Overall length, Bumper to link (mm) | 3552 | 3576 | ||
|---|---|---|---|---|---|
| Overall width witd tires (mm) | 1650 | 1775 | |||
| Wheelbase (mm) | 1930 | 2047 | |||
| Overall height to top ROPS/Cab (mm) | 2584 | 2476 | 2614 | 2506 | |
| Total weight without ballast (kg) | 1995 | 2200 | 2085 | 2290 | |
| Tires | Front (options) | 9.5 - 20 | 11.2 - 20 | ||
| Rear | 13.6-28 | 14.9-28 | |||
| PTO | Type (options) | Independent / GSP | Independent / GSP | ||
| Base speed (rpm) | 540/750/1000 | 540/750/1000 | |||
| Hydraulic | Control system (options) | Position / Draft | Position / Draft | ||
| Remote Ports (options) | 4 (front), 4 (rear) | 4 (front), 4 (rear) | |||
| Engine | Engine Hp(kW) | 46.4(34.6) | 55.8(41.6) | ||
| Rated speed (rpm) | 2600 | 2600 | |||
| Traveling system | Transmission Type (options) | Synchro shuttle | Synchro shuttle | Synchro shuttle | Synchro shuttle |
| No. of speed | 16FX16R/32FX32R(with creeper) | ||||
| Forward Speed (Km/h) | 0.19~27.9 | 0.2~29.3 | |||
| Category | U6020 ROPS | U6020 CABIN | U6030 ROPS | U6030 CABIN | |
| Dimensions & Weight | Overall length, Bumper to link (mm) | 3576 | |||
|---|---|---|---|---|---|
| Overall width witd tires (mm) | 1775 | ||||
| Wheelbase (mm) | 2047 | ||||
| Overall height to top ROPS/Cab (mm) | 2640 | 2530 | 2640 | 2530 | |
| Total weight without ballast (kg) | 2091 | 2296 | 2091 | 2296 | |
| Tires | Front (options) | 11.2 - 20 | 11.2 - 20 | ||
| Rear | 14.9-28 | 14.9-28 | |||
| PTO | Type (options) | Independent / GSP | Independent / GSP | ||
| Base speed (rpm) | 540/750/1000 | 540/750/1000 | |||
| Hydraulic | Control system (options) | Position / Draft | Position / Draft | ||
| Remote Ports (options) | 4 (front), 4 (rear) | 4 (front), 4 (rear) | |||
| Engine | Engine Hp(kW) | 56.3(42) | 61.6(45.6) | ||
| Rated speed (rpm) | 2500 | 2500 | |||
| Traveling system | Transmission Type (options) | Synchro shuttle | Synchro shuttle | Synchro shuttle | Synchro shuttle |
| No. of speed | 16FX16R/32FX32R(with creeper) | ||||
| Forward Speed (Km/h) | 0.2~28.2 | 0.2~28.2 | |||
| Category | ULTRA65 ROPS | ULTRA65 CABIN | LS554 | ||||
| Dimensions & Weight | Overall length, Bumper to link (mm) | 3576 | 3691 | ||||
|---|---|---|---|---|---|---|---|
| Overall width witd tires (mm) | 1775 | 1696 | |||||
| Wheelbase (mm) | 2047 | 2046 | |||||
| Overall height to top ROPS/Cab (mm) | 2640 | 2530 | 2545 | ||||
| Total weight without ballast (kg) | 2091 | 2296 | 2473 | ||||
| Tires | Front (options) | 11.2 - 20 | |||||
| Rear | 14.9-28 | ||||||
| PTO | Type (options) | Independent / GSP | Independent | ||||
| Base speed (rpm) | 540/750/1000 | ||||||
| Hydraulic | Control system (options) | Position / Draft | |||||
| Remote Ports (options) | 4 (front), 4 (rear) | 4 (rear) | |||||
| Engine | Engine Hp(kW) | 61.1(45.6) | 54.3 (40.5) | ||||
| Rated speed (rpm) | 2500 | 2400 | |||||
| Traveling system | Transmission Type (options) | Synchro shuttle | |||||
| No. of speed | 16Fx16R | ||||||
| Forward Speed (Km/h) | 1.2~28.2 | 1.2 ~ 29.2 | |||||
