Product Name
Tractor (V Series)
Model Name
LSV704, LSV754, LSV804
Size
-
Weight
-
Product Details
LSV704, LSV754, LSV804
CABIN - LSV704, LSV754, LSV804
ROPS - LSV704, LSV754, LSV804
Features
High ground clearance High ground clearance protects the crops on the ground and guarantees high performance, especially when working in a wet field. | Standard air-conditioner (Cabin model only) The standard air-conditioning system ensures a comfortable work environment during hot days. | Productivity in narrow working places Higher steering angle minimizes turning radius. It gives better performance in narrow working place. |
Large Fuel Tank Get larger fuel tank size (100ℓ) for longer operation time and more convenience for fuel injection. | Full flat deck Full flat deck and rubber mat ensure user friendly working condition. |
Specification
| Category | LSV704 C | LSV704 R | LSV754 C | LSV754 R | LSV804 C | LSV804 R | |
| Dimensions & Weight | Overall length, Bumper to link (mm) | 4109 | |||||
|---|---|---|---|---|---|---|---|
| Overall width witd tires (mm) | 1978 | ||||||
| Wheelbase (mm) | 2342 | ||||||
Overall height to top ROPS (mm) | 2566 | 2827 | 2566 | 2827 | 2566 | 2827 | |
| Total weight without ballast (kg) | 3120 | 2930 | 3120 | 2930 | 3120 | 2930 | |
| Tires | Front | 11.2 - 24 | |||||
| Rear | 16.9 - 30 | ||||||
| PTO | Type | Independent | |||||
| Base speed (rpm) | 540/750 | ||||||
| Hydraulic | Control system *options | Position/Draft | |||||
| Implement pump (lpm) | 39.1 | ||||||
| Category, 3 pt hitch | CAT Ⅱ | ||||||
| Hitch lift capacity, Link end (kgf) | 2447 | ||||||
| Remote ports *options | 2 (rear) | ||||||
| Engine | Type | 4-Stroke, direct-injection, Water-cooled | |||||
| Model | 4G33TC | ||||||
| Emission | Stage III | ||||||
| Engine Hp (kW) | 69.1 (51.5) | 74 (55.2) | 78.9 (58.8) | ||||
| PTO | 58.7 | 62.9 | 67.1 | ||||
| Rated speed (rpm) | 2300 | ||||||
| Displacement (cc) | 3260 | ||||||
| Fuel Tank Capacity (L) | 100 | ||||||
| Traveling system | Transmission Type *options | Synchro shuttle | |||||
| No. of speed | F12 × R4 | ||||||
| Forward Speed (Km/h) | 2.2 ~ 32.2 | ||||||
