product Image

TOP

Motion Interface Unit
Model Name
SOMFY-1822067
Series
Others System
Data
Equipment Overview & Function
Manufacturer information
provider logo
Max Digital TechDVI, HD-SDI, AV, RGB, Total control, Total control system developer
Problem with product info?
Update request
Manufacturer
Max Digital Tech[Link]
Brand
-
SKU
45158
Product Name
Motion Interface Unit
Model Name
SOMFY-1822067
Size
-
Weight
-
Product Details

1. Description

○ This Interface Unit is to control electron motion system such as Electronic
    screen, Electronic Elevation, and electronic Cover Board.

○ It is connected to Main control Unit (MMCU-100S, 150S, 200S, 250S, 300S) for
    Remote Control Operation.

○ A controller is available for current detection. Lamp and LED switch for overload
    detection. They are associated with self control motor function and group
    relay box.


2. Panel Drawing

Max Digital Tech Motion Interface Unit SOMFY-1822067



3. Specification

○ General Part
  - Input Voltage : AC 220V 60Hz
  - DC 24V Lamp Switch
  - Fuse : 250v 3.15A
  - Relay Contact Capacity : AC 250V ,10A
  - Over Load Function Selection Switch
  - Motor Extent : 70 - 450W

○ Case Part
  - Dimensions : 80(W) * 140(H) * 50(D) mm
