Pneumatic Conveying System and Plant
Model Name
-
Series
Environmental Business Dept
Data
-
Manufacturer information
provider logo
SAMWON E&B

Blower Manufacturer, High Pressure Blower, Thermal Power Station Fan, Marine Boiler Fan, Tunnel Axial Fan & Jet Fan and more

Problem with product info?
Update request
Manufacturer
SAMWON E&B
Brand
-
SKU
22611
Product Name
Pneumatic Conveying System and Plant
Model Name
-
Size
-
Weight
-
Product Details

Advantage/Disadvantage of Pneumatic Conveying System

Advantage

- Relatively free conveyance route
- Secondary pollution prevention with closed conveyance
- Easy operation and maintenance with simple structure
- Big transportation capacity per unit area
- Less initial investment
- No noise or remnant generated


Disadvantage

- Large power required.
- Pipe wear and destructed particle (Prevention with low speed high concentration conveyance)\
- Limited materials for conveyance
- Difficult transportation of moist materials
- Adhesive materials



Types of conveying Methods

- Low Pressure Forced Feed Type

: General Industries (Wood Chip, Pellet)
: Conveying Speed (15-20 m/sec.)
: Mixture Ratio (0.1-10)


- High Pressure Forced Feed Type

: Long distance/large quantity transportation
: Conveying Speed (15-30 m/sec.)
: Mixture Ratio (750)


- Absorption Type

: Ship Unloading (Crops, Alumina), Food Process, Toxicant Conveyance
: Conveying Speed (15-30 m/sec.)
: Mixture Ratio (0.1-15)


- Plug Transportation Type

: Conveyance of fragile particle (Crystal Particle)



SAMWON E&B
Blower Manufacturer, High Pressure Blower, Thermal Power Station Fan, Marine Boiler Fan, Tunnel Axial Fan & Jet Fan and more
SAMWON E&B Co., Ltd. established in 1978 has manufactured, delivered and constructed various kinds of blowers required for the entire industries to heavy chemistry plant, subway and tunnel ventilation equipment, thermal power plant, sewage water treatment plant, etc., and has a lot of delivery records such as all of public buildings in downtown and apartments. In addition, we changed the company name from SAMWON wind power Co., Ltd. used for 20 years or more to SAMWON E&B Co., Ltd. from initial letters of Environment & Blower on Jan 1, 2001 in order to protect health of the people from air pollution by cooperating technology on atmosphere area of environmental industry with DUCON, USA on the basis of technologies and experiences that have lead the blower industry. SAMWON E&B Co., Ltd. has manufactured, delivered and constructed Variable Pitch Control Axial Flow Fan,, High Pressure Blower, etc. in the nation by importing important parts of them under partnership with Wood, Sweden, for deficient domestic technology in order to introde more advanced technologies. In addition, we have acquired certificates such as K Mark, GQ Mark, etc. from Korea Industrial technology Agency and Small and Medium Business Administration and ISO 9001 from Small and Medium Business Certificate Center after acquired KS for the blower from Korea Standard Association first in Korea in order to supply good quality products to the customers and contributed to export a lot. We will serve the customers with better products and research and development and do our best in the future.
