DESCRIPTION | SPECIFICATION | ||
SUBSTRATE | PAPER | ||
COATING TYPE | COMMA KNIFE OR BAR COATING TYPE | ||
COATING WIDTH | MAX. 1090mm | ||
MACHINE SPEED | MAX. 120m/min | ||
DIA. & SURFACE | Dф(160 ~ 200mm), L (800 ~ 1150mm) | ||
UNWINDER | DIAMETER | MAX.ф1100mm | |
CORE CHUCKING | AIR EXPANSION SHAFT | ||
TYPE | 2 SHAFT STAND TYPE | ||
FOAMING CHAMBER | NOZZLE TYPE | MULTI HOLE NOZZLE TYPE & JET NOZZLE TYPE | |
HEATING SOURCE | GAS BURNER | ||
EWINDER | TYPE | SUPLEX TURRET WINDING TYPE | |
DIAMATER | MAX. Φ1100mm | ||
CORE CHUCKING | AIR EXPANSION SHAFT | ||
REEL CHANGE | AUTOMATIC SPLICING SYSTEM |
