product Image

TOP

Solid State Relay (DC Load type)
Model Name
WYNSG1C205D4
Series
Solid State Relay
Data
NG_Type080402.DWG
Manufacturer information
provider logo
WOONYOUNGVarious electronic control equipment manufacturer, UL transformer, UL trans, NCT, Reactor, SSR, TPR, SMPS, SPD, Noise filter and more
Problem with product info?
Update request
Manufacturer
WOONYOUNG
Brand
-
SKU
131701
Product Name
Solid State Relay (DC Load type)
Model Name
WYNSG1C205D4, WYNSG1C210D4, WYNSG1C220D4, WYNSG1C230D4, WYNSG1C240D4
Size
-
Weight
-
Product Details
Model No WYNSG1C205D4 WYNSG1C210D4 WYNSG1C220D4 WYNSG1C230D4 WYNSG1C240D4
TYPE WYNSG
Certification
Rating 200VDC
Input 4VDC~32VDC
Output 200VDC
Capacity 5A 10A 20A 30A 40A



Specifications and Features

These product series have acquired certification. They carry capacity of DC10~200V, 5~40A and are used on general resistive load and on general inductive load. These SSR feature an LED that can identify the state of power ON/OFF according to input control.



WOONYOUNGVarious electronic control equipment manufacturer, UL transformer, UL trans, NCT, Reactor, SSR, TPR, SMPS, SPD, Noise filter and more
Woonyoung is a leading company that specializes in manufacturing and developing various Electronics Controls. Our products are Electric Power System - Transformer, High/Low Voltage Reactor, Noise cut transformer, Automation Solution - Solid State Relay (SSR), Thyristor (TPR), Noise Filter, Switching Mode Power Supply (SMPS), Harmonic Filter Solution - Active Harmonic Filter (AHF), Passive Harmonic Filter (PHF), Micro Surge Filter (MSF), Sine Wave Filter (SWF), Zero Sequence Harmonic Filter (ZHF), and Protection & Measuring - High/Low voltage CT, VT, MOF, Protective Relay, Earth Leakage Detector (ELD), Ground Fault Relay (GFR), Zero Phase Current Transformer (ZCT), Woonyoung has the clear vision for Power Electronics Industry in 21st century. In order to being a one of the major companies in global market, we are firmly building the infrastructure such as human, technology, and future-oriented corporate culture.Representing young industrial spirit, we will move forward as a superb company in 21st century's Power Electronics Industry. We will also actively cope with the rapidly changing world market through constant challenge, product internationalization, innovative R&D, and best technology.
