● Rating : 300V 10A
● Insulation Resistance : More Than 1000MΩ DC 500V
● Withstand Voltage : AC2000V Per Minute
● Wire Size / Range : AWG16~22
● Maximum Acceptable Temperature : -40°C ~ +85°C
No |
Component Part |
Material |
Standard |
Plated |
Remark |
1 |
Frame |
P.B.T. |
UL94V-0 |
- |
- |
2 |
Terminal #1 |
BRASS |
C2680R |
Sn |
- |
3 |
Terminal #2 |
BRASS |
C2680R |
Sn |
- |
4 |
Screw |
SWCH10A |
- |
Ni |
M3 * 7 |
5 |
WASHER |
SPCC |
Ni |
□6.8 * 6.8 |
