Ø NB (mm) | Ø NC (mm) | N (mm) | R (mm) | SW (mm) | V (mm) | Internal Thread | Part number |
12 | 8 | 5 | 0.5 | 10 | 10 | M6x1 | NXT12M6 |
16 | 10 | 6 | 0.5 | 13 | 15 | M8x1.25 | NXT16M8 |
20 | 10 | 6.5 | 1 | 17 | 15 | M8x1.25 | NXT20M8 |
25 | 16 | 7 | 1 | 22 | 15 | M8x1.25 | NXT25M8 |
25 | 16 | 7 | 1 | 22 | 15 | M10x1.5 | NXT25M10 |
25 | 16 | 7 | 1 | 22 | 15 | M12x1.75 | NXT25M12 |
25 | 16 | 7 | 1 | 22 | 15 | M12x1.25 | NXT25M12F |
32 | 20 | 10 | 1 | 27 | 15 | M8x1.25 | NXT32M8 |
32 | 20 | 10 | 1 | 27 | 15 | M10x1.5 | NXT32M10 |
32 | 20 | 10 | 1 | 27 | 15 | M12x1.75 | NXT32M12 |
32 | 20 | 10 | 1 | 27 | 15 | M12x1.25 | NXT32M12F |
40 | 26 | 12 | 1.5 | 36 | 20 | M12x1.75 | NXT40M12 |
40 | 26 | 12 | 1.5 | 36 | 20 | M12x1.25 | NXT40M12F |
40 | 26 | 12 | 1.5 | 36 | 20 | M16x2 | NXT40M16 |
40 | 26 | 12 | 1.5 | 36 | 20 | M16x1.5 | NXT40M16F |
50 | 32 | 14 | 1.5 | 46 | 25 | M16x2 | NXT50M16 |
50 | 32 | 14 | 1.5 | 46 | 25 | M16x1.5 | NXT50M16F |
50 | 32 | 14 | 1.5 | 46 | 25 | M20x2.5 | NXT50M20 |
50 | 32 | 14 | 1.5 | 46 | 25 | M20x1.5 | NXT50M20F |
62 | 42 | 17 | 2 | 56 | 30 | M20x2.5 | NXT62M20 |
62 | 42 | 17 | 2 | 56 | 30 | M20x1.5 | NXT62M20F |
62 | 42 | 17 | 2 | 56 | 30 | M27x3 | NXT62M27 |
62 | 42 | 17 | 2 | 56 | 30 | M27x2 | NXT62M27F |
79 | 52 | 20 | 2 | 75 | 40 | M27x3 | NXT79M27 |
79 | 52 | 20 | 2 | 75 | 40 | M27x2 | NXT79M27F |
79 | 52 | 20 | 2 | 75 | 40 | M33x3.5 | NXT79M33 |
79 | 52 | 20 | 2 | 75 | 40 | M33x2 | NXT79M33F |
95 | 64 | 24 | 2 | 88 | 50 | M33x3.5 | NXT95M33 |
95 | 64 | 24 | 2 | 88 | 50 | M33x2 | NXT95M33F |
95 | 64 | 24 | 2 | 88 | 50 | M42x4.5 | NXT95M42 |
95 | 64 | 24 | 2 | 88 | 50 | M42x2 | NXT95M42F |
122 | 80 | 28 | 2 | 115 | 63 | M42x4.5 | NXT122M42 |
122 | 80 | 28 | 2 | 115 | 63 | M42x2 | NXT122M42F |
122 | 80 | 28 | 2 | 115 | 63 | M48x5 | NXT122M48 |
122 | 80 | 28 | 2 | 115 | 63 | M52x2 | NXT122M52F |
