Video

Compression

H.265/H.264/MJPEG

Frame rate

Max 60fps @ 1920x1080

Bitrate

Primary : 32Kbps ~ 16Mbps, Secondary : 32Kbps ~ 4Mbps

Resolution

320x240 ~ 1920x1080

Streaming

Quad Streaming - Primary : H.265/H.264, Secondary x 3 : H.265/H.264/MJPEG

Bitrate Control

CBR / VBR / Hybrid / Adaptive CBR / Smart CBR

Burn-in OSD

Multi-lingual

Output

Composite

Audio

Compression

G.711 / AAC(Option)

Sampling rate

G.711 : 8 KHz, AAC(Option): 32 kHz / 44.1 kHz / 48 kHz

Bitrate

G.711 : 64Kbps, AAC(Option): 64Kbps/128Kbps

Streaming

G.711 : Full-duplex, AAC(Option): Full-duplex

Input/Output

1 x Line-In (mono), 1 x Line-Out (mono)

PTZ Control

Operating angle

Horizontal: 360°, Vertical: 210°(-15° ~ 195°)

Operating speed

PAN /TILT: Preset Max Speed(540°/sec) / Manual Max Speed(450 °/sec)

PTZ functionalities

Preset (500), Pattern (4), Swing (8), Group (8), Auto parking

Network

Protocol

IPv4/v6, TCP, UDP, IGMP(Multicast), ICMP, DHCP, HTTP, HTTP, FTP, SNMP,

SMTP, UPnP, WS-Discovery, Zero Configuration,

NTP, SRT, MPEG-TS, RTP, RTSP, RTMP, DDNS

Security

Password protection, IP address filtering, HTTPS encryption

API

Truen protocol/SDK, ONVIF, PSIA, MPEG-TS

Interface

Ethernet 10/100/1000 base-T (RJ-45)

Event / Alarm

Event sources

Motion, Sensor input, Client disconnection

Event actions

Notification(E-mail), FTP, PTZ preset, Alarm control, Recording

External devices

4 x Sensor-In (dry contact, NO/NC), 2 x Alarm-Out (dry contact, NO)

1 x RS-485 port : PTZ control etc.

General

Power Supply

Min AC24V/2.5A, PoE+(Power over Ethernet) : 802.3at

Power Consumption

AC24V : Max 35W, PoE+ : Max 29W

Operating Temperature

-30°C ~ 70°C

Operating Humidity

20% ~ 80% RH

Edge Storage

SD/SDHC/SDXC slot (Max 512GB)

Dimensions (W x H x D)

Ø240 x 305.6mm, Ø177.7

Weight

3,680g (without bracket)
