Video

Compression

H.265/H.264/MJPEG

Frame rate

Max 30fps @ 1920x1080

Bitrate

Primary : 32Kbps ~ 16Mbps, Secondary x3 : 32Kbps ~ 4Mbps

Resolution

320x240 ~ 1920x1080

Streaming

Primary : H.265/H.264, Secondary x 2 : H.265/H.264/MJPEG

Burn-in OSD

Multi-lingual

Audio

Compression

G.711

Sampling rate

G.711 : 8 KHz

Bitrate

G.711 : 64Kbps

Streaming

Full-duplex

Input/Output

1 x Line-In (mono, RCA type), 1 x Line-Out (mono, RCA type)

Network

Protocol

IPv4/v6, TCP, UDP, IGMP(Multicast), ICMP, DHCP, HTTP, HTTP, FTP, SNMP, SMTP, UPnP, WS-Discovery, Zero Configuration,

NTP, SRT, MPEG-TS, RTP, RTSP, RTMP, DDNS

Security

Password protection, IP address filtering, HTTPS encryption

API

Truen protocol/SDK, ONVIF, PSIA, MPEG-TS

Interface

Ethernet 10/100 base-T (RJ-45)

Event / Alarm

Event sources

Motion, Sensor input, Client disconnection

Event actions

Notification(E-mail), FTP, PTZ preset, Alarm control, Recording

External devices

1 x Sensor-In (dry contact, NO/NC)

1 x Alarm-Out (dry contact, NO)

1 x RS-485 port : PTZ control etc.

General

Power Supply

Min DC12V, PoE(Power over Ethernet) : 802.3af

Power Consumption

DC12V/PoE : Max 12W

Operating Temperature

-10°C ~ 50°C ( 14°F ~ 122°F )

Storage Temperature

-10°C ~ 50°C ( 14°F ~ 122°F )

Operating Humidity

20% ~ 80% RH

Storage Humidity

20% ~ 80% RH

Edge Storage

Micro SD/SDHC/SDXC slot (Max 512GB)

Dimensions (W x H x D)

Ø85.7 x 297.9(L) [mm]

Weight

1,630g
