Automatic valve manufacturer, For Power plant, Energy, Petro chemical, Oil refining, Food, Paper, Shipbuilding, Pharmaceutical field
Application
■ Liquefied Natural Gas(LNG)
■ Liquefied Oxygen Gas
■ Liquefied Helium Gas
■ Chemical Plants
■ Power Plant-Fossil Fuel
■ Foundries
■ Fats, Oils, Fatty
Specification
Valve Size | 100A ~ 1200A, 4” ~ 48” |
Seat Material | PCTFE(KEL-F), METAL(Harden) |
Actuator Type | Double Acting Cylinder |
Operating Media | Compressed Dry Air |
Operating Pressure | 3~7kgf/㎠ |
Fluid Temperature | -196~450℃ |
Rating | ANSI #150, #300, #600 |
Body Material | Austenite Stainless Steel |
Design Code | ANSI B16.34, 16.5, ISO5752, BS5155, MS SSP44, API6FA, 607, 598 |
Accessory | Solenoid Valve, Limit Switch, Air Filter & Regulator, Speed Control, E/P Positioner, Manual Handle |
Model | Valve Size | H | L | Cv | Weight (Kg) |
|
mm | inch | |||||
SA150 |
150 |
6” |
610 | 395 | 906 | 80 |
SA200 |
200 |
8” |
640 | 410 | 1730 | 96 |
SA250 |
250 |
10” |
665 | 455 | 2810 | 147 |
SA400 |
400 |
16” |
807 | 555 | 7850 | 335 |
SA500 |
500 |
20” |
932 | 625 | 12880 | 555 |
SA800 |
800 |
32” |
1240 | 830 | 37210 | 1606 |
SA1000 |
1000 |
40” |
1590 | 1190 | 62320 | 3040 |
