Model Name

NOVASTIM CU-FS1

Series

-

Data

CU-FS1

Manufacturer information

CU Medical Systems

Medical equipment manufacturer, AED, CPR

Inquiry

Problem with product info?

Update request

Manufacturer

CU Medical Systems

Brand

-

SKU

28025

Product Name

-

Model Name

NOVASTIM CU-FS1

Size

-

Weight

-

Product Details

<tab title="Functions & Features">

▶ Easy

2 Channel type, Easy to use with just 3 steps .

▶ Economic

Increasing strength & Decreasing pain in the upper & lower extremities

▶ Efficient

Optimized programs for different muscle groups

Intended Use

Maintain or improve active range of motion and function

Functional walking aid for paralytic (Hemiplegia)

Training to heal shoulder Subluxation for paralytic (Hemiplegia)

Maintain or improve active range of motion and function for the patient with spinal cord injury

<tab title="Specifications">

• Output waveform: Monophasic or Biphasic

• Maximum output current:

Single waveform: 100 mA±10% (Load Impedance: 500Ω)

Virtual waveform: 36 mA±10%

• Output display: LCD screen & LED indicator

• Frequency: 1~99 Hz±10%

• Timer : 0~99 min. ±15% with digital timer

• Pulse width : 20~700㎲±10%

• 2 Channels available(Ch1, Ch2)

• Safety

① Zero(Output)start

② Overcurrent device(Fuse)

③ Constant current control

• Specification

Output current: Constant current, Maximum output 100mA

Output waveform : Monophasic or Biphasic

Frequency : 1~99 Hz

Pulse width : 20~700㎲

Warm up : 0~59 min.

Cool down : 0~59 min.

Ramp up : 0~9.9 sec.

Ramp down : 0~9.9 sec.

Burst on : 0.1~9.9 sec., 1~59 sec.

Burst off : 0.1~9.9 sec., 1~59 sec.

Impedance range : 0~0.5㏀

maximum output current : 100 mA±10%

Pulse interval : 20~990㎲

<tab title="Accessories">

Device(1), Carrying case(1), Lead line(1), Electrode 48R(1), Hand Switch(1), Foot switch(1), AA Alkaline battery(4), AA rechargeable battery, Battery charger(1), User’s manual(1)
