Manufacturer of Industrial, Agricultural & Construction Pump
-Discharge amount (m3/min)0.18 ~ 0.8㎥/m
-Total pump head (m):5 ~ 10m
-Temperature (℃) :Max. 90℃
-Number of rotations (RPM) :1750 rpm (4 Pole)
-Caliber (mm) :40 ~ 100mm
- The liquid enters the pump’s suction mouth, and the suction mouth and the discharge mouth are on opposite sides, on one line.
- It is a pump that could be installed directly on horizontal or vertical pump.
- Low lift feed head circulation
- Convection circulation, recirculation
- Guarantee of high efficiency and reliability
- The shaft seal or impeller may be replaced without the detachment of the pump casing.
- The flow with gradual with low-noise operation
- The examination, maintenance and repair of the motor, impeller and shaft are convenient.
- The product could be installed in either vertical or horizontal form.
- Dust protection is unnecessary
