Manufacturer of Industrial, Agricultural & Construction Pump
-Discharge amount (m3/min)0.08 ~ 3 ㎥/m
-Total pump head (m):17 ~ 152m
-Temperature (℃) :Max. 90℃
-Number of rotations (RPM) :1450, 1750rpm (4 Pole)
-Caliber (mm) :40 ~ 150mm
- The rotator and the volute casing is assembled in linear form, with the impeller inducing the water directly to casing.
- High lift is gained with the increased number of pumps (impellers)
- Water supply for apartment and high rise building.
- Fire hydrant and sprinkler of high rise building.
- Water supply for boiler, water-intake, irrigation water
- Drainage of high ground area such as mine.
- Double volute method was used to widen the scope of pump output with good efficiency.
- The structure was simple with good durability, with less noise due to its small size and light weight
- The compatibility of the parts is fine due to its standardized design.
- The design was made appropriately according to pump specifications, preventing overload.
