Harvesting Belt "LE METEOR"
Model Name
TMH 80
Series
Harversting Belts / Conveyors
Data
-
Manufacturer information
provider logo
DELECROIX HARVESTING

Haversting Equipment Manufacturer, Agricultural, Harvesting Belts, Vegetable Trailers, Floretting Machine and more

Problem with product info?
Update request
Manufacturer
DELECROIX HARVESTING
Brand
-
SKU
138030
Product Name
Harvesting Belt "LE METEOR"
Model Name
TMH 80, TMH 100
Size
-
Weight
-
Product Details

Range of harvesting belts with PVC belt (drive by pinions), adapted to the needs of the harvester.

  • From 8.00m to 10.00m useful length
  • Complementary belt to the Delecroix or La Bretonne trailer
  • Robust and functional harvesting belt, with a large capacity to increase productivity
  • Simplified harvest


RANGE

TYPES TMH 80 TMH 100
Useful length 8.00 m 10.00 m
Number of boxes 4 5
Number of boxes
hydraulic unfolding
3 3
Number of boxes
manual unfolding
1 2


STANDARD EQUIPMENT

Steel starter frame
2 first steel boxes with aluminum boxes
Subsequent boxes and last aluminum element
Cap 0.75 m (interior trailer reception area)
PVC strip 350 mm wide
Stainless steel upper slides for guiding the belt
Cleats 60 mm high, at 250 mm intervals
Grip roller drive and tension maintenance system
Hydraulic motorization with variable speed drive on distributor
Conveyor stop by photoelectric detector
Left exit with front controls (or right exit, rear controls)


OPTIONS

Standard packing table 3 or 4 boxes perpendicular and swiveling
Wrapping table 3 or 4 boxes parallel to the belt (possible addition of rolls)
Hydraulic displacement in the trailer: external rollers in rail or on the edge of the platform
Stainless steel trays on the first 2 steel boxes and stainless steel edges on the aluminum boxes (excluding the last element)
Pass-through frame for passage over pallets
Pivot for right or left outlet
Epoxy paint (primer)
No custom cleats
Hydro-electric reel
Right exit with front controls (or left exit, rear controls)

In addition to this, you will need to know more about it.

DELECROIX HARVESTING
Haversting Equipment Manufacturer, Agricultural, Harvesting Belts, Vegetable Trailers, Floretting Machine and more
DELECROIX offers harvesting solutions for vegetable applications : harvesting belts, harvesting trailers, mobile floretting machines and also offers a range of spare parts. Our mission is to provide solutions that deliver three benefits: 1. High yield of harvest time which divides by three the number of pickers or collectors. 2. The conveyor belts reduces the work load of the pickers team 3. Reduction of the percentage of the damaged vegetables. You can get grants for the purchase of your equipment, check your eligibility. We have more than 25 years of experience manufacturing and offering adapted and also customized solutions for vegetable producers. We are working with a worldwide network of dealers (35% export), and we are open to welcome new dealers. Our goal is to sell and implement with our new partners our vegetable harvesting machineries in Asia. Our commitment: Respecting deadlines is harvest day! We are committed to establishing a schedule that respects the deadlines agreed with our customers. We also take into account the handling time for each material.
