Check Valve
Model Name
SFCV Series
Data
-
Manufacturer information
provider logo
Eunha Air Tech

Air dryer, Pressure vessel, Storage tank, Energy saving device and more

Problem with product info?
Update request
Manufacturer
Eunha Air Tech
Brand
-
SKU
54105
Product Name
Check Valve
Model Name
SFCV Series
Size
-
Weight
-
Product Details

ㆍFeatures The check valve has supplemented the defects of other products from other supplier and therefore has solved the problem of pressure drop due to valve breakage and malfunction or an unstable dew point. The valve is a self-made product.

ㆍProblems of each type

Type Problems
DUAL
PLATE
* Breakage due to a deteriorated swing;
* Malfunctions due to abrasion between the connection hole and the pin and disc;
* ΔP due to a narrow open area.
SWING

* Enlarged discs due to the long distance between the sides; bigger size and wear can be made due to the

impact between the connection drive connecting disc with the body and thus making the product malfunction.

Close running may produce impact that could break the arm.

DISC
PLATE

* The horizontal piping connection may produce not only fluid force that

pushes when disc plate is connected to the body guide but also return the spring’s

repulsive power to abrade the guide and to malfunction.

DISC
PLATE
SPRING
RETURN
* The horizontal piping connection may produce deflection due to the weight of the disc at the bottom that connects to the shaft cylinder causing it to malfunction.



ㆍProduction Specification
Size: 50A to 250A
Highest working pressure (standard): 10 ㎏/㎠
Highest working temperature: 300 ℃
Material: BODY — SCS13
 DISC — SCS13
 BUSH — ALBC3
 SHAFT — STS304
Warranty period: 4 years
