X-ray Film Auto Processor
Model Name
GAP-201
Data
GAP-101
Manufacturer information
provider logo
GMEDI

Medical equipment manufacturer, Film processor, Endotracheal tube holder, Suction ball electrode and more

Problem with product info?
Update request
Manufacturer
GMEDI
Brand
-
SKU
55762
Product Name
X-ray Film Auto Processor
Model Name
GAP-201
Size
-
Weight
-
Product Details

- Easy to control by using microprocessor chip

- Best durability   adequate humidity

- Minimum installation space

- Various developing time 90 / 120 / 180 / 210 sec (60 sec, Option)



Specification

Model GAP-201
Film Transport Method Continuous roller transport
Film Type and Sizes Sheet film
4”×4” (10×10cm)
8”×10”(20.3×25.4cm)
10”×12”(25.4×30.5cm)
11”×14”(28×35cm)
14”×14”(35×35cm)
14”×17”(35×43cm)
Processing Capacity 35×43cm - 45 Sheet / Hour
25×30cm - 70 Sheet / Hour
cess Cycle Swatching Available by a service engineer
Tank Volume Developer 3.5 Liter
Fixer 3.5 Liter
Wash 3.5 Liter
Replenishment Tanks Developer 25 Liter
Fixer 25 Liter
Wash 25 Liter
Dimension Height 540 mm
Width 575 mm
Length 716 mm
Power Supply AC. 110/220V single phase 50/60 hz
Power Consumption Stand-by : 0.55 kw. Operation : 1.1kw
(Save Energy World No One)
Weight Approx.35kg (without solutions)
Accessories Standard Replenishment Tank
Exhaust Hose, Measuring Cup
Installation Parts kit
Operation Manual(CD-ROM)
Option Water Filter Assembly, Table

*The above specifications are subject to change without prior notice
