- The Allowable tolerance of dimension is -0, +5mm
- The dimension can be changed for improvement without notice
HAG-25D2 1.5KW
STANDARD 1.5kw | Unit | 50Hz | 60Hz | |||||||
200V | 220V | 380V | 415V | 440V | 220V | 240V | 380V | 440V | ||
LOAD CURRENT | A | 9.7 | 8.8 | 5.1 | 4.6 | 4.4 | 8.5 | 7.8 | 4.9 | 4.2 |
STARTING CURRENT | A | 27.0 | 28.7 | 16.6 | 15.2 | 14.3 | 30.1 | 27.6 | 17.4 | 15.0 |
RPM | rpm | 1400 | 1700 | |||||||
EFFICIENCY | % | 74.8 | 76.3 | |||||||
RATED TORQUE | kg/m | 1.04 | 0.86 | |||||||
STARTING TORQUE | % | 210 | 200 | |||||||
INSULATION | CLASS | B | B | |||||||
WEIGHT | kg | 28.0 | 28.0 | |||||||
BRAKE TORQUE | % | 250 | 300 |
- Single Voltage is applied except for 200V, 220V, and 380V
