Manufacturer of fertilizer spreader, manure spreader, Mist sprayer and more
* Two type special shutter spreads both granule fertilizers and organic compost
* Various materials spreading : organic compost, granule fertilizers, lime, sand, salt, wood chip and etc
* Scoop-up the fertilizer on the ground by pushing buckets(Blade mounted)
* Bucket function allows easy loading of organic compost and fertilizer
* Spinner : Hydraulic motor
* Agitator : Hydraulic motor
* Feeding : Auger by hydraulic motor
* Hopper, precention, spinner, vanes and etc : Stainless Steel
* Types : General(IOD-600H), Mid(IOD-750H), Big(IOD-900H)
SPECIFICATION
MODEL |
IOD-600H |
IOD-750H |
IOD-900H |
CAPACITY(ℓ) |
780 |
970 |
1160 |
N. DISC |
1 |
1 |
1 |
WIDTH(mm) |
1500 |
1800 |
2100 |
SPREADING |
8~16 |
8~16 |
8~16 |
FEATURE |
1. HYDRAULIC |
1. HYDRAULIC |
1. HYDRAULIC |
MODEL |
IOD-600J |
IOD-750J |
IOD-900J |
CAPACITY(ℓ) |
780 |
970 |
1160 |
N. DISC |
1 |
1 |
1 |
WIDTH(mm) |
1500 |
1800 |
2100 |
SPREADING |
8~16 |
8~16 |
8~16 |
FEATURE |
1. HYDRAULIC |
1. HYDRAULIC |
1. HYDRAULIC |
MODEL |
IOD-600A |
IOD-750A |
IOD-900A |
CAPACITY(ℓ) |
780 |
970 |
1160 |
N. DISC |
1 |
1 |
1 |
WIDTH(mm) |
1500 |
1800 |
2100 |
SPREADING |
8~16 |
8~16 |
8~16 |
FEATURE |
1. HYDRAULIC |
1. HYDRAULIC |
1. HYDRAULIC |
