HIGHLY RELIABLE RF COAXIAL CONNECTORS WITH 500 MATING CYCLE

ITT Cannon has been providing highly reliable RF coaxial connectors for over 25 years to customers worldwide. With a life of 500 mating cycles, and an operating temperature of -65°C to +165°C, ITT Cannon’s RF coaxial straight plug connectors are a perfect fit for Aerospace, Industrial, Handheld, and Transportation markets.

These RF coaxial Connectors have a moisture proof interface with three available mating options. SMA plugs are environmentally sealed, intermateable with all SMA connectors, operate up to 18 GHz, and have a threaded coupling method. SMB RF coaxial connectors have a snap on coupling and operate up to 4 GHz, while SMC RF coaxial connectors have a threaded coupling and operate up to 10 GHz.

Features and Benefits

• Standoffs on PCB mounts of commercial SMA series for cleaning and inspection
• Stainless steel coupling nuts with gold or passivated finish on cable plugs
• SMA plugs are environmentally sealed using a gasket
• Intermateable with all SMA connectors currently available
• Crimp/solder contact on straight plug for performance and speed of assembly on commercial SMA series
