SPECIFICATION
Model | Displacement (cc/rev) | Pressure (kgf/cm²) | Max.Speed (rpm) | Rated Torque (kgf·m) | Max.Fluid Temperature | Permissible Viscosity Range | Weight (kg) | ||||
100% | 50% | Rated | Max | 100% | 50% | 100% | 50% | ||||
JRT-500 | 499 | 250 | 210 | 250 | 500 | 1000 | 155 | 78 | 70℃ | 12~500(cSt) | 95 |
DIMENSIONS
STRAIGHT SHAFT | TAPER SHAFT |
INVOLUTE SPLINE SHAFT (KS R2001) | SQUARE SPLINE SHAFT |
