Excavator Hydraulic Quick Coupler manuafacturer
ITEM | Unit | KTR600 | Application Model |
---|---|---|---|
Overall Length(L) | mm | 545 ~ 568 | SOLAR130W, SOLAR130W-3, SOLAR140W-4, DX140V, EC130, EC140BLC, EC145B, MX6W, MX132LC, MX135W, MX6LC, ROBEX1300W, ROBEX1400LC-7, CAT312, DH05W, HE130W |
Overall Height(H) | mm | 948 ~ 977 | |
Overall Width(W) | mm | 354 ~ 419 | |
Installation Length(L1) | mm | 380 ~ 487 | |
Installation Width(W1) | mm | 260 | |
Reference DWG. |
