product Image
CCTV Camera
Model Name
KSC-TP24R
Series
CCTV(Camera)
Data
카탈로그-금성보안-KSC-TP24R
Manufacturer information
provider logo
KEUMSUNG SECURITY

Security system, CCTV

Problem with product info?
Update request
Manufacturer
KEUMSUNG SECURITY
Brand
-
SKU
125545
Product Name
CCTV Camera
Model Name
KSC-TP24R
Size
-
Weight
-
Product Details

Full HD x32 Zoom IR Speed Dome IP Camera

▪1/2.8” 2.42 Mega Pixel CMOS 센서

▪ 광 학 줌32x, 디지털 줌16x

▪ 최 대 60fps@1080p 전송속도

▪ Q u a d Streaming 지원

▪최저조도 Color 0.05Lux

▪ I R LED 투광거리최대150M

▪ F a n / Heater 하우징, 온도 자동조절가능

▪지능형 모션 감지

▪ 안 개 보정 기능

▪스케줄 녹화, POWER ON ACTION

▪ 한 글 텍스트OSD 표출

▪ I P 6 6 방진,방수 등급/ IK10 충격보호등급

▪ONVIF 지원

이미지 센서1/2.8" CMOS
총 화소수2.42 Megapixels
광학 줌 렌즈X32 Optical Zoom, f=4.44mm(Wide)~142.6mm(tele), F1.6 to F4.4
디지털 줌X16
최저조도

Color: 0.2Lux, BW: 0.01Lux, Color

Dss:0.003Lux, BW DSS: 0.0001Lux,

WDR/BLCON/OFF
DSSON/OFF
전자셔터스피드2~1/12,000sec
Day/ NightAuto (ICR) / Color / B/W
화이트 밸런스ATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium
FlickerlessOn/Off
회전 범위Pan 360°Endless/Tilt -15°~195°
회전 속도프리셋: 700°/sec, 수동: 0.024°/sec ~ 120°/sec
프리셋255 Preset
투어6Group(10 preset/Goup)
압축코덱H.264/MJPEG
해상도1080p, 720p, D1~QQVGA
비디오 전송 속도60fps@1080p
비디오 스트리밍Simultaneously H.264 and MJPEG (Quad Streaming)
아날로그 출력Compositex1
압축코덱AAC/G.711
입력/출력Line level 1 input/ 1 output (Full Duplex)
센서/알람센서입력 4/ 알람 출력 2
센서 입력4 In
센서 출력2 Replay Out
SD카드(옵션)SD Card Interface Support
인터페이스Ethernet 10/100 Based-T (RJ-45)
프로토콜TCP,IP,HTTP,DHCP,PPPoE,FTP,DNS,DDNS,NTP,ICMP,SNMP,SMTPE,RTP,RTSP,SSL
방식RS-485
보호등급IP66/IK10
사용전원AC12V 6A
동작온도-50℃ ~55℃
사이즈/무게248()X399.5(H)mm /7.1kg

KEUMSUNG SECURITY
Security system, CCTV
KeumSung Security is a company servicing Integrated SI systems for our valued customers. Our Integrated SI system is our specialized system that provides hypervigilance capabilities for use in multiple dimensions for security in such areas as crime and disaster prevention.We hold strictly to the policy of 24/7 with these services to prevent a single gap in coverage. Although we confidently suggest our system because of its superior capabilities and high level of functioning, we have never stopped in our efforts to improve our system.We are continually putting our efforts into investigation and resource improvement in order to make ours the number one system in the market, at the same time serving our national clients and other challenging businesses. In 1989, KeumSung Security started as a tech cooperation partner of LG Honeywell (Honeywell Korea today) and has walked along with the history of security solution development in Korea.From its moment of establishment, KeumSung Security has aimed for “the security of societies through IT technology.” To reach that goal, we have overcome the fluctuating economy and many other in-and-outside obstacles, and we have experienced continued growth within our sector.We are never satisfied with standing still. We are constantly expanding our vision, the dream we have had from the start. To achieve this, KeumSung Security promises you that we will support innovation. We will criticize ourselves. We will not stop. And most importantly, we will be KeumSung Security, who always consider your safety as top priority.
