Specification
Form factor
Dimensions 1U Rack Optimized, 322x44x183mm(W x H x D)
Platform
Processor OCTEON Plus CN50xx Single/Dual Core MIPS64 Based Embedded Processor
System Memory
Memory Type DDR2 667MHz SO-DIMM 32bit
Memory Capacity Up to 2GB DDR2 Memory
Network interface
2x Copper GbE(RTL8212)
4x Copper Switch(RTL8366)
Storage
Storage Interface 1x 2.5' SATA II HDD
CF 1x Compact Flash
Peripheral
USB 1x USB 2.0 Port
Serial 1x Console Port(RJ45 Type)
Expansion & Option Card
1x Mini PCI
Display
LEDs Power LED, HDD LED, Bypass LED
Power
Watt SMPS 12V adapter
Input 100V~240V AC 50~60MHz auto range
Environmental Parameters
Temperature Operating 0~40℃, Storage -20~75℃
Humidity(RH) Operatiog 5~85%, Storage 5~95%
