KR2200
Model Name
KR2200
Series
Rotary Joint
Data
ROTARY JOINT
Manufacturer information
provider logo
KWANG JIN(KJC)

Rotary joint, Swivel joint, Heating cover, Ceramic board, Rock wool board

Problem with product info?
Update request
Manufacturer
KWANG JIN(KJC)
Brand
-
SKU
59166
Product Name
-
Model Name
KR2200
Size
-
Weight
-
Product Details
Size Range 6A~80A(1/8"~3")
Max. Pressure 10kg/㎠ (150PSI)
Max. Temperature 100℃ (210℉)
Max. Rotation Speed
   6A~25A(1/8"~1") 1,000RPM
   32A~40A(1-1/4"~1-1/2") 700RPM
   50A~80A(2"~3") 500RPM
Media Water , Air , Gas , Oil



- Enables high spped rotation at high pressure
- Low Friction
- Stainless steel shaft and springs
- Silicon-Carbide sealing for KRS model
  - Extended running hours than KR model
  - Protection against media contamination by rust, scale,chips & other harmful abrasives
