대형 Beveling Machine
Model Name
Tube 2000A
Series
Beveling Machine
Data
-
Manufacturer information
provider logo
KYOUNGDONG

Manufacturer of Sawing M/C & Pipe beveling M/C

Problem with product info?
Update request
Manufacturer
KYOUNGDONG
Brand
-
SKU
30656
Product Name
대형 Beveling Machine
Model Name
Tube 2000A
Size
-
Weight
-
Product Details

•KYOUNG DONG's Facing Machine is an all-purpose facing machine of cross-head type endowed with modernity developed by rich ideas and excellent technology.

•A wide range of workings can be made including pipe and tube ends, pipe outside diameter surfaces, joint flange surfaces, etc. and preparation and centering are very easy because the facing head is freely movable to fit the part of the material to be worked.

•It can also store a programmed configuration so as to make it easy to be operated by a novice.

•초대형 Pipe 전문 Beveling Machine입니다.

•임대 및 가공 업무도 도와드리고 있습니다.

DESCRIPTION

UNIT

Tube 2000

Cutting Diameter

800~2000

Cutting thickness

200

Face Plate Dia

1240

Spindle R.P.M

r.p.m

10~60

Main Motor

22

X-axis Motor(Servo)

3.5

Z-axis Motor(Servo)

5

X-axis Distance

180

X-axis Speed

m/min

0.5

Z-axis Distance

200

Z-axis Speed

m/min

1.8

Oil Mist





Tank Capacity

1.5

Power Source

V



Control Source

V

220

DIMENSION

Length

2400

Width

2400

Height

2660

Net weight

12000





KYOUNGDONG
Manufacturer of Sawing M/C & Pipe beveling M/C
Since its founding 40 years making a good machine. Since founded in 1973, our company has made a great effort to become a Leading company in the Cutting, Beveling machinery which are widely used In the various pipes. Our products are recognized as a key products, widely used in the fields of Petroleum, natural gas, power supply construction, boiler and nuclear power. Our products are exported to worldwide and famous for high quality and Famous brand at home and abroad. The equipment are the main equipment to make a spool on the home and abroad oil chemical plant.
