Characteristic
• Static minimized
• Antistick of roll to roll is minimized
• Change of adhesive tape is easy.
• Single·Series / Forward·Backward automatically.
• Auto return cleaning is allowed.
Option
1. ANTI ALARM GUIDE
2. ROLL CONVEYOR
3. FLAT BELT CONVEYOR
Specification
|
LSCR-60D(양면용) |
LSCR-60S(단면용) |
Material Size |
500 × 650mm |
500 × 850mm |
Material Thickness |
0.05 ~ 3mm |
0.05 ~ 3mm |
Cleaning Speed |
50 ~ 400mm/s |
50 ~ 400mm/s |
Dimension(L × W × H) |
910 × 905 × 1200mm |
910 × 905 × 1200mm |
* Special specification is made to order.
* Appearance and specifications in this homepage are subject to change without notice.
