SDI&HD ↔ SDI Converter
Model Name
ISH-3G
Series
Converter & Extender
Data
SDI&HD ↔ SDI Converter
Manufacturer information
provider logo
MasterVideo signal testing equipment manufacturer, Generator, Multi media player and more
Problem with product info?
Update request
Manufacturer
Master
Brand
-
SKU
45545
Product Name
SDI&HD ↔ SDI Converter
Model Name
ISH-3G
Size
-
Weight
-
Product Details

IHS-3G converts HD-SDI to HDMI to HDMI or DVI and HDMI or DVI to HD-SDI, VGA to DVI, Supports output resolution up to Full HD (1080p).


-. Use high-quality converter chipset

-. High quality circuit design is appropriate for broadcasting system

-. Supports up to Full HD (1080p)

-. VIDEO INPUT : RGB(444), YCbCr(444), YCbCr(422)

-. VIDEO OUTPUT : YCbCr(422), RGB(444)

-. Audio data : 12S / 48Khz only

-. Not to support HDMI, DVI same time output (HDMI preferred)

-. KC certification : MSIP-REM-BLX-ISH-3G


INPUT CONNECTOR

 DVI, HDMI Format(RGB444, YCbCr444, YCbCr422)
 DVI-D , HDMI 19Pin Female

 OUTPUT CONNECTOR

 SDI Format YCbCr(422), SMPTE-424M, 292M, 259M
 SDI BNC(75OHM)

 AUDIO IN/OUPUT

 I2S / 48KHz

 POWER

 DC 5V/3A // 100~240V

 DIMENSION(mm)

 117 x 105 x 33 (mm)

 WEIGHT(Kg)

 0.5Kg

 ENVIRONMENT

-10°C~60°C / Humidity 80%

 CERTIFICATION

 MSIP-REM-BLX-ISH-3G



Master SDI&HD ↔ SDI Converter ISH-3G
