Product Details

<tab title="NON-POLARIZING CUBE BEAMSPLITTERS (NP-51-K-040-068-10/90)">


Price : $930.00 per unit



SKU : NP-51-K-040-068-10/90

[Standard Specification]

Non-polarizing cube beam splitter

Size : 50.8mm x 50.8mm x 50.8mm(+0 / -0.2mm)

Material : N-BK7

Surface Quality : 60-40 (Scratch-Dig)

Surface Flatness : Lambda /4 at 633nm

Angular deviation : 3 arc minutes

Clear aperture : 85%

coating : AR coating

Ravg less than 0.5% at 405nm



[Model Specficiation]

coating : NPBC coating

T = 10% (+/-3%) at 405nm

R = 90% (+/- 5%) at 405nm

p-Ts less than 5% at 405nm

</tab>
<tab title="NON-POLARIZING CUBE BEAMSPLITTERS (NP-51-K-040-068-20/80)">


Price : $930.00 per unit



SKU : NP-51-K-040-068-20/80

[Standard Specification]

Non-polarizing cube beam splitter

Size: 50.8mm x 50.8mm x 50.8mm(+0 / -0.2mm)

Material: N-BK7

Surface Quality: 60-40 (Scratch-Dig)

Surface Flatness: Lambda /4 at 633nm

Angular deviation : 3 arc minutes

Clear aperture: 85%

coating: AR coating

Ravg less than 0.5% at 405nm



[Model Specficiation]

coating : NPBC coating

T = 20% (+/-5%) at 405nm

R = 80% (+/- 5%) at 405nm

Tp-Ts less than 5% at 405nm




Price : $930.00 per unit

SKU : NP-51-K-040-068-30/70

[Standard Specification]

Non-polarizing cube beam splitter

Size: 50.8mm x 50.8mm x 50.8mm(+0 / -0.2mm)

Material: N-BK7

Surface Quality: 60-40 (Scratch-Dig)

Surface Flatness: Lambda /4 at 633nm

Angular deviation : 3 arc minutes

Clear aperture: 85%

coating: AR coating

Ravg less than 0.5% at 405nm

[Model Specficiation]

coating : NPBC coating

T = 30% (+/-5%) at 405nm

R = 70% (+/- 5%) at 405nm

Tp-Ts less than 5% at 405nm
