Product Name
Yaw Drive
Model Name
-
Size
-
Weight
-
Product Details
Controlling the blade pitch to the optimal wind energy generating.
Type | Nomial Torque (nM) | Peak Torque (nM) | Gear tatio. | Dimension | ||||||
D1 | D2 | D3 | d | L1 | L2 | L3 | ||||
1.5MW | 7,500 | 16,500 | 1/164 | 320 | 380 | 420 | 12-17 | 241 | 348 | 27 |
2.0MW | 11,000 | 23,000 | 1/160 | 360 | 420 | 460 | 12-17 | 280 | 380 | 32 |
2.5MW | 13,000 | 28,600 | 1/158 | 400 | 460 | 500 | 16-17 | 320 | 420 | 32 |
NOTE
- L4 : according to Motor maker
- Mxz, W : agreed with Customer
- above specifications would bw subject to the be changed without notice
- When applied, Consult NARA in advance
