Converting an alternating current that receives from a CT sensor into a standard process signal.
ㆍMonitoring of power line and power supply current.
ㆍCentralized monitoring and controlling of motors, pumps or heaters by DCS.
ㆍTrue R.M.S. sensing.
ㆍ1 or 2 outputs are available from 1 input.
ㆍContains overvoltage protection circuit.
ㆍTransformer isolation type.
Products Detail
SSN-ACC | |||
INPUT | OUTPUT1 | OUTPUT2 | POWER |
AC 0~1A | 0~10V | 0~10V | AC110V |
AC 0~5A | 0~5V | 0~5V | AC220V |
Other | 0~1V | 0~1V | |
1~5V | 1~5V | ||
4~12mA | 4~12mA | ||
0~20mA | 0~20mA | ||
12~20mA | 12~20mA | ||
4~20mA | 4~20mA | ||
Other | Other |
Technical Data
Model | SSN-Series | Function | Transmit DC signal in isolated conditon |
Input | mA, RTD, 2-Wire, Potentiometer, T/C, Pulse, CT, PT | Output | DC Siganl (4-20mA, 1-5V) Max : 2ch |
Power | AC 110V or AC 220V | Accuracy | 0.1% / Full scale |
Display | None | Response Time | 0.5 sec (0~90%) |
Front Adjustment | Zero and Span 5% | Weight | About 400g |
Mounting | Wall mounting | Dimensions(mm) | W40 * H129 * D 138 |
