Air motor, F.O hose handling davit, Pump davit, Suez canal search light davit and more
[SPECIFICATION - SUEZ MOORING BOAT HANDLING DAVIT]
|
MODEL |
SWL |
WORKING |
MAX. LIFT |
HOISTING |
SLEWING |
WIRE |
DIMENSION (mm) |
||||||
|
(ton) |
(m) |
(m) |
MOTOR |
SPEED |
MOTOR |
SPEED |
mm |
A |
B |
D |
E |
F |
|
|
(PS) |
(m/min) |
(kW) |
(m/min) |
||||||||||
|
SMSMD |
2 |
2~4.5 |
25 |
5.4 |
5~10 |
1.9 |
0.5 |
12 |
1100 |
3000 |
406 |
1400 |
2500 |
|
3 |
2~4.5 |
25 |
5.4 |
5~10 |
1.9 |
0.5 |
12 |
1100 |
3000 |
508 |
1400 |
2500 |
|
|
4 |
2~4.5 |
25 |
7.6 |
5~8 |
1.9 |
0.5 |
14 |
1100 |
3000 |
660 |
1400 |
2500 |
|
|
5 |
2~4.5 |
25 |
7.6 |
5~8 |
1.9 |
0.5 |
14 |
1100 |
3000 |
870 |
1400 |
2500 |
|
[SPECIFICATION - PROVISION DAVIT]
|
MODEL |
SWL |
WORKING |
HOISTING SPEED |
SLEWING SPEED |
LUFFING TIME |
ELEC.MOTOR FOR HOISTING |
DIMENSION (mm) |
||||
|
(ton) |
(m) |
(m/min) |
(rpm) |
(mm) |
(kW) |
A |
B |
D |
E |
F |
|
|
SMSMD |
2 |
3~6 |
10 |
0.5 |
50 |
3.7 |
1000 |
1800 |
700 |
1200 |
2.5 |
|
3 |
4~8 |
8 |
0.5 |
50 |
5.5 |
1000 |
2000 |
700 |
1200 |
3 |
|
|
4 |
4~8 |
5 |
0.5 |
85 |
11 |
1000 |
2200 |
810 |
1500 |
3.5 |
|
|
5 |
5.5 |
5 |
0.5 |
85 |
11 |
1000 |
2300 |
810 |
1500 |
3.5 |
|
|
8.5 |
7.2 |
4 |
0.5 |
130 |
11 |
1700 |
3900 |
810 |
1500 |
4.1 |
|
- WORKING AIR PRESSURE : 6~9 kg/㎠
- DRIVING POWER : AIR MOTOR , ELECTRIC MOTOR , MANUAL
- ADDITIONAL SLEWING DEVICE ARE RECOMMENDED FOR DAVIT WITH CAPACITY OF SWL 2TON OR ABOVE.
