Carbon Black Tester
Model Name
SM-CBT-60L
Series
Cable Fire Testers
Data
-
Manufacturer information
provider logo
Sungmin Instruments

Measurement tester about cable, High frequency spark tester, AC spark tester, Laser external diameter measuring equipment

Problem with product info?
Update request
Manufacturer
Sungmin Instruments
Brand
-
SKU
37033
Product Name
Carbon Black Tester
Model Name
SM-CBT-60L
Size
-
Weight
-
Product Details

This tester is used to measure the amount of carbon black containing polyethylene, polypropylene, and polybuthylene. The amount of carbon black is determined by weighing the sample which is thermally decomposed in N2 gas. To thermally decompose a sample, an electrical furnace and accessories are available.

Product Specs

Model SM-CBT-60L
Temperature control type Digital Program P, I, D Control
Heater capacity 2KW
Temperature control range 0~900°C ±1°C (Max)
Safety device over-temperature prevention sensor
Combustion plate 29(D)mm x 600(L)mm
Temperature sensor K-Type (CA)
Attached device flow gauge 10ℓ / min, trip, drying tube, stopper, glass tube
Size 500(W) X 450(H) X 340(D)mm
Power 220VAC 50/60Hz 1Phase
