The UG2000D and UG2000DM spray gun cleaners are the best value on the market today.

Models

UG2000D / UG2000DM

UG2000DM

• In addition to the features above, the UG2000DM has a Flow-through brush for additional manual washing. The brush is especially useful for removing hardened paint. The bristles and handle are constructed from solvent resistant polypropylene.
• The flow of solvent through the brush is activated by a foot pedal and powered by a  2″ dual diaphragm pump. Flow is adjustable.

Both Models Share The Following Features

• Top loading. Cleans 2 spray guns in under 2 minutes.
• Washing is activated by a wash timer and powered by a long-lasting dual-diaphragm pump that outputs 3.7 gallons of solvent per minute.
• Wash Tank is constructed from stainless steel for longer life. The tank size is 17.25″ w x 13.5″ d x 14″ h.
  Mounting adapters fit popular conventional cup systems and disposable cup systems to deliver solvent to thoroughly flush the paint channel.
• 14 swirl action jets deliver cleaning solvent to wash overspray from the spray guns.
• Threaded air caps keep the air passage of the spray gun dry.
• Pump halts immediately, if the lid is raised during cleaning, to prevent exposure to solvent, providing a safe operation.
• Stainless steel mesh filter keeps solvent cleaner and debris from reaching the diaphragm pump.
• CE Approved.

Operation

Place the spray gun on the mounting adapter in the cleaning tank and turn the automatic timer. A 4-inch diaphragm pump drives cleaning solvent up through 1) the mounting adapters to flush the paint channel of the spray gun and 2) through 14 spray jets to wash overspray from the outside of the gun. Solvent drains back into the customer supplied pail, for reuse, a green approach. Two guns are cleaned in 2 minutes.

Specifications

• Requires minimum of 85 PSI, 2 CFM of clean dry air. Pressure regulator is built in.
• 4″ dual diaphragm pump with unique shuttle valve for long life, output is 3.7 gal/min (14 L/min).
• Cleans solvent-borne paint from the following types of spray guns: gravity, siphon, pressure and cleans pots.

Shipping Dimensions: 20″w x 17″d x 45″h (51cm W x 43cm D x 114cm H) Shipping Weight: 70 lb (32kg)

Product Dimensions: 17″w x 14″d x 2″h (43cmW x 36cmD x 5cmH)
